DMP Item number: 7674458
DMP
55,00 €*
available immediately
Shipping weight 0,42 kg
Here is an overview of the force applied to the brake piston when combining different calipers and pump combinations.
In general, an increase in the slave piston with the same master piston will always result in an increase in the braking force with a longer lever travel, however.
Conversely, when installing a brake pump with a larger piston but the same brake caliper, a decrease in the force applied to the brake piston can be assumed, with a smaller lever travel, however. Thus the brake becomes more direct, but requires more lever force for the same brake performance.

driving piston (brake caliper)

25mm

28mm

30mm

32mm

dispenser piston
(Pump)

10mm

375 N

p>470 N

540 N

614 N

11mm

310N

389 N

446 N

p>508 N

12mm

260 N

327 N

375 N

427 N

13mm

p>222 N

278 N

320 N

364 N

14mm

191 N

240 N

p>276 N

313 N

15mm

167 N

209 N

240 N

273 N

16mm

146 N

184 N

211 N

240 N

17mm

130 N

163 N

187 N

213 N


AI-translation>/em>/sub>
