Faco Item number: 6950009
Faco
1 Rating
Type: Leg shield luggage compartment
Fits: V50, V90, PV125, ET3
Finish: unpainted, without holder
Mounting: retaining plates or frame mounting
Tip: Dry-build before painting
Benefit: more storage space in the leg shield
149,00 €*
available immediately
Shipping weight 2,15 kg

Luggage compartment FACO for Vespa V50, V90, PV125 and ET3

Leg shield luggage compartment for classic Vespa Smallframe models such as V50, V90, PV125 and ET3.

The FACO luggage compartment is the classic solution for creating additional storage space in the leg shield for tools, papers or small items. Space is at a premium, especially on smallframe models - the compartment makes sensible use of the available space and remains visually close to the familiar accessory solutions of the time.

FACO Smallframe Leg shield compartment unpainted without holder

What the luggage compartment is for

More storage space: useful for small items, tools, gloves or documents
classic accessory look: matches the style of the Vespa Smallframe models
neat solution: things disappear into the leg shield instead of lying loose in the vehicle

Installation: two sensible ways

There are two common options for mounting the luggage compartment - depending on whether the frame is already painted or the vehicle is currently being assembled.

Variant 1: Retaining plates for finished frames

Installation using special retaining plates (available separately)
Retaining plates are screwed to the frame
Holes must be drilled for this
well suited for already painted frames

Variant 2: ideal for restoration or repainting

Screws can be welded directly to the frame
Alternatively, sheet metal pockets can be used into which the screw heads are inserted from the side
Advantage of the sheet metal pockets: screws remain replaceable
the luggage compartment itself has matching sheet metal tabs that are placed on the threads and fixed with nuts

Important before painting: Dry-build

We recommend a complete dry-build, i.e. an assembly in the unfinished state, before any painting. This allows any necessary adjustments to be made quickly without damaging freshly painted parts later. Afterwards, the final assembly is twice as much fun.

Surface and preparation

The luggage compartment is prepared for further surface treatment and should always be individually adjusted and checked before final painting.

Brief technical overview

Manufacturer: FACOFACO
TypeLeg shield luggage compartment
Suitable forVespa V50, V90, PV125, ET3
Finishunpainted, without holder
Mountingvia retaining plates or individual attachment to the frame

Conclusion

The FACO luggage compartment is a practical accessory for smallframe models if storage space is required in the leg shield. If you plan the installation carefully and adapt the compartment before painting, you will have a harmonious solution for classic Vespa conversions that is suitable for everyday use.


This is how we ensure, that reviews come from real consumers.
Neuecker M. 05/25/2025
Cladding parts
Material
Stahl
Execution
unlackiert
Number of parts included
1

OEM numbers (for comparison purposes only)
Piaggio:
113200, E.1947, E1947
Scooter Center:
6950009
