The Spanish carburettor manufacturer ARRECHE has become famous with the licensed constructions of the legendary, English Amal carburettors.

The high quality ARRECHE carburettors are offered for a wide range of engines. The carburettors are basically tuned for the respective engine type, so you have a good starting point to find the perfect setup.

The ARRECHE carburettors are very grateful in the tuning and mostly you find a well running setup very easy. The ARRECHE carburettors are excellent up to the mid race / race range. Since there is only one needle for the carburettors, the largest mixing tube should be used in the race area.

ARRECHE carburettors are cheap to buy, easy to tune and robust in construction.
AI-translation

Rate this article now and let us know what you think.
Carburetor
Main nozzle size
65
Main nozzle type
Mikuni (4/042)
Secondary nozzle type
Arreche
Needle type
Arreche
Slider type
Rundschieber
Choke type
elektrisch
Connection type Intake manifold
Gummiverbindung
Position of mixture screw
links
Fuel hose position
rechts
Fitting type
M6 x 0.75
Float chamber material
Metall
Size of secondary nozzle
25
Needle size
S1
Mixing tube size
105
has Powerjet
nein
Slider size
3
Height
95 mm
Width
59 mm
Depth
73.7 mm
Relative connection height
49.9 mm
Connection width air filter
35 mm
Connection width of intake manifold
23 mm
Fuel hose connection width
6.5 mm
has oil connection
ja
has vacuum connection
ja
Venturi size
17.5 mm
Connection type Air filter
geklemmt
Position of idle throttle screw
rechts
