Cylinder -ATHENA 72 cc Alu Ø46mm- Piaggio Bravo, Ciao, Boxer (gudgeon pin = Ø 10mm) - milling engine casing is required

1 Rating
199,00 €*
available immediately
Shipping weight 0,15 kg
Information on product safety
Report error
Racing cylinder of the Athena brand. High quality aluminum for perfect heat dissipation, thermal stability and high continuous power. Multiport overcurrent system and piston with two stable piston rings.

Good basis for steady tuning. Original carburettor can be used, for even more power a bigger carburettor should be installed.

Delivery without cylinder head, therefore a bigger one should be used, or the standard head should be adapted.

Designed for models with the 10 piston pin diameter. On some engine cases the cylinder mount must be spindled/adjusted.

AI-translation

This is how we ensure, that reviews come from real consumers.
Anonym  06/22/2015

le produit exellent

Rate this product now
General
Performance class
Sport

Piston pin
Diameter
10 mm

Cylinder
Drill hole
46 mm
Type of cooling
luftgekühlt
Displacement
72 cm³
Motor type
2-Takt
Material
Aluminium
Piston raceway material
Keramik
Cylinder gasket set included
ja
Cylinder head included
nein
Outlet shape
3-teilig
Exhaust assembly
Stutzen

Crankshafts
Stroke
43 mm

Piston
Number of piston rings
2
Piston manufacturing method
gegossen

Piston rings
Piston ring type
L-Ring (Dykes-Ring), Rechteck-Ring

Piston clips
Piston clip type
Doppel G-Typ
Wire gauge Piston clip
1,0mm
