Dellorto Item number: 7673556
Dellorto
1 Rating
149,00 €*
available immediately
Shipping weight 0,55 kg
The Dellorto carburettors are not only in the scooter sector a constant. In many vehicles Dellorto is even an original equipment manufacturer.

Thanks to the incredible variety of mixing tubes and especially needles, you can find a setting that works quite quickly with the Dellorto PHBL carburettors. Unfortunately the individual areas are not very cleanly separated from each other, so that a lot of experience or experimentation is necessary to adjust the carburettor really perfectly. A task that takes time.

Thanks to the widespread use of Dellorto carburettors, the spare parts supply is very good.

The PHBL carburettors are often used on the Maxi automatic scooters, where they are very well suited for fast road engines.Lambretta/B> engines, carburettors with 24 and 25 mm passages are usually used when the original air filter box is to be retained. B>Vespa/B> PHBL carburettors are particularly popular on small frames, where the PHBL can be used to build really fast engines.
AI-translation

This is how we ensure, that reviews come from real consumers.
Wolfgang B. from Freiburg 07/29/2025
Carburetor
Main nozzle size
100
Main nozzle type
Dellorto 6mm (6413)
Secondary nozzle type
Dellorto 5mm (1486)
Choke nozzle type
Dellorto (7746)
Needle type
Dellorto D (2265)
Slider type
Rundschieber
Choke type
manuell Hebel
Connection type Intake manifold
Klemmverbindung
Position of mixture screw
rechts
Fuel hose position
rechts
Fitting type
M6 x 0.75
Float chamber material
Kunststoff
Size of secondary nozzle
50
Choke nozzle size
60
Needle size
D22
Mixing tube size
AQ264
has Powerjet
nein
Slider size
40
Height
125 mm
Width
85 mm
Depth
90 mm
Relative connection height
70 mm
Connection width air filter
38 mm
Connection width of intake manifold
28.57 mm
Fuel hose connection width
7.7 mm
has oil connection
nein
has vacuum connection
nein
Venturi size
24 mm
Connection type Air filter
geklemmt, geschraubt
Position of idle throttle screw
rechts

OEM numbers (for comparison purposes only)
Dellorto:
02733
