DRT Item number: 7672963
DRT

Secondary shaft -DRT Gear Flame Runner- Vespa V50, PV125, ET3, PK50, PK80, PK125 S-XL - 10-14-17-20 teeth (used with original gearbox)

2 Ratings
Type: RUNNER auxiliary shaft, DRT Flame Runner
Teeth: 10-14-17-20 (Z20-17-14-10)
Gearbox: 4-speed smallframe, use with original gearwheels
Thread: M11, nut included
199,00 €*
available immediately
Shipping weight 0,2 kg
Information on product safety
Report error

Auxiliary shaft -DRT Gear Flame Runner- Vespa Smallframe 4-speed (10-14-17-20)

The DRT Flame Runner is an auxiliary shaft for Vespa Smallframe 4-speed engines. It is used with original gearwheels and relies on an adapted gradation with short 3rd and extra short 4th gear. The aim is a better gear connection if the engine loses too much speed between third and fourth gear in series or in the tuning setup.

short 3rd gear extra short 4th gear for original gear wheels M11 nut DRT Smallframe

Advantages at a glance

Better gear connection: shorter 3rd and 4th gears reduce the drop in speed when shifting up.
Original gear wheels remain: no adjustment to the gear wheels necessary, the auxiliary shaft takes over the gradation.
For powerful smallframe setups: particularly interesting in the 100 to 130 cc range, when the fourth gear would otherwise be too long.
Durable material: made of hardened and tempered steel for high continuous loads.
M11 nut: fine thread design, suitable for DRT construction.

Technical background

With smallframe engines in particular, the jump from 3rd to 4th gear is often too large. The engine falls below the usable speed after shifting, especially when touring or when the gear ratio and tire rolling circumference do not match perfectly. With the RUNNER auxiliary shaft, the gradation in 3rd and 4th gear is shorter so that the engine remains in the appropriate speed window after shifting.

Note: A clean overall gear ratio always results from the primary, transmission, tire rolling circumference and engine concept. The gearshift cross and spacing should be checked for the setup.

Primary recommendations

DRT recommends the following primary ratios as a guide for typical setups:

Polini 100 cc: 2.88 (24/69) or 2.86 (21/60)
Polini 130 ccm: 2.55 (27/69) or 2.61 (23/60)
Quattrini M1, M1L, Parmakit: 2.73 (22/60) or 2.76 (25/69)

Technical data

The productAuxiliary shaft DRT Flame Runner 4-speed
Teeth10-14-17-20
Charactershort 3rd gear, extra short 4th gear
Usewith original gearwheels
ThreadM11, nut included
OEM number (comparison)8000000014887 / a01488

Suitable for the following models (excerpt)

Vespa 50 S 2° and Special (V5B3T, V5B4T)
Vespa 50 SR (V5SS2T), Vespa 50 SS (V5SS1T)
Vespa 90 R, 90 SS, 90 Racer
Vespa 100 2°
Vespa 125, PV125, ET3
Vespa PK50 to PK125, S, XL, XL2

FAQ

No, this RUNNER auxiliary shaft is designed to run with original gear wheels. The shorter gradation is created via the auxiliary shaft.
Particularly for 100 to 130 cc setups, when the fourth gear with standard gearing is too long or the engine drops out of the usable speed range after shifting.
This is how we ensure, that reviews come from real consumers.
Anonym 03/16/2015

Sehr gutes Produkt.

Anonym 03/16/2015

Well made and easy to use.
